This cam has very aggressive ramps and requires an upgraded spring package, billet rod, and flywheel. Use bored stock or Tillotson carb. Great cam if you have a lift check requirement but want maximum open valve duration.
This cam has very aggressive ramps and requires an upgraded spring package, billet rod, and flywheel. Use bored stock or Tillotson carb. Great cam if you have a lift check requirement but want maximum open valve duration.
Engine: 196cc OHV Clone
Recommended Class: Modified
Target (MAX) RPM: 8200-8400
Spring Pressure (In / Ex): 32 lbs
Valve Lash (IN/EX): .003"
Ignition Timining: 32 Deg BTDC
INTAKELIFT: .278
Dur @ .050": 258.7 Deg.
C/L: 108 ATDC
EXHAUSTLIFT: .278
DUR @ .050": 258.6 Deg.
C/L: 110 BTDC
THIS IS A TOOL STEEL BILLET CORE
Processed and ground by the hard working employees of DynoCams in the USA.
